| Parameter | Specification |
|---|---|
| Detection Range | 70MHz – 6GHz full‑band scanning, detection, and display |
| Key Detection Bands | 433MHz, 530MHz, 750MHz, 800MHz, 900MHz, 1.2GHz, 1.4GHz, 2.4GHz, 3.3GHz, 5.2GHz, 5.8GHz |
| Detection Distance | ≥10 km (depending on conditions) |
| FPV Video Detection | 500MHz – 6GHz full‑band scanning and display |
| Video Detection Distance | ≥1.5 km (real‑time video viewing supported) |
| Jamming Bands | 700‑840MHz, 860‑930MHz, 1170‑1290MHz, 1400‑1490MHz, 1560‑1620MHz,
2385‑2490MHz, 5150‑5250MHz, 5725‑5850MHz |
| Jamming Distance | ≥3 km (depending on conditions) |
| Direction Finding Accuracy | ≤ ±15° RMS |
| Protection Rating | IP66 |
| Weight | Detection unit: ≤17 kg; Jammer unit: ≤30 kg |
| Dimensions | Detection unit: 400 mm (diameter) × 516 mm (height); Jammer unit: 465 mm (L) × 275 mm (W) × 510 mm (H) |
